410 430 Material Stainless Steel Wire Mesh Woven Wire Mesh Plain Weave Style

Brand Name : R&K

Model Number : SS-22

Certification : SGS

Place of Origin : Hebei

MOQ : 1 squaremeter

Price : Negotiate

Payment Terms : L/C, D/P, T/T, Western Union，PayPal

Supply Ability : 1000 squaremeter per week

Delivery Time : 5-8 workday

Packaging Details : inside with paper tube,Then waterproof paper covered,Finally in a wooden case or pallet

Material : 304 stainless steel

Usage : Filter

Weave style : Plain weave

Aperture : 0.1mm

Color : Silver

Advantage : High temperature resistant

Type : Wire cloth

Hole shape : Square hole

Contact Now

410 430 Material Stainless Steel Wire Mesh Woven Wire Mesh Plain Weave Style

There are many types of stainless steel mesh, in addition to the commonly used 304, 316, there are other categories, such as 410 material, 430 material and so on.

410 stainless steel wire mesh is magnetic and has good corrosion resistance, and 430 stainless steel wire mesh has good stress corrosion and oxidation resistance.

410/430 stainless steel wire mesh has better thermal conductivity than austenitic stainless steel series. Its thermal expansion coefficient is smaller than austenite. Thermal fatigue resistance, adding stable element titanium, the mechanical properties of welded parts are good.

Magnetic, also called magnetic stainless steel wire mesh, stainless steel wire mesh, magnetic stainless steel wire mesh.

Grade	C	Si	Mn	P	S	Ni	Cr
SUS410	≤0.15%	≤1.00%	≤1.00%	≤0.03%	≤0.04%	≤0.60%	11.50~13.50%
SUS430	≤0.12%	≤0.75%	≤1.00%	≤0.040%	≤0.030%	≤0.60%	16.00~18.00%

410 430 Material Stainless Steel Wire Mesh Woven Wire Mesh Plain Weave Style

Package of the stainless steel wire mesh

410 430 Material Stainless Steel Wire Mesh Woven Wire Mesh Plain Weave Style

Parameter of stainless steel mesh

mesh	Wire Diameter		Aperture		Open Area	Weight
	Wire Diameter		Aperture		Open Area	Weight
	Inch	MM	Inch	MM	(%)	(kg /Square meter)
1x1	0.08	2.03	0.92	23.37	92	2
2X2	0.063	1.6	0.437	11.1	87.4	2.5
3X3	0.054	1.37	0.279	7.09	83.8	2.7
4X4	0.047	1.19	0.203	5.16	81.2	2.7
5X5	0.041	1.04	0.159	4.04	79.5	2.6
8X8	0.02	0.5	0.105	2.675	71	1
9X9	0.02	0.5	0.091	2.32	67.7	1.1
10X10	0.025	0.64	0.075	1.91	74.9	2
12X12	0.02	0.508	0.063	1.6	75.9	1.5
12X12	0.022	0.55	0.062	1.567	54.8	1.815
14X14	0.02	0.508	0.051	1.3	71.9	1.8
14X14	0.0177	0.45	0.054	1.36	75.14	1.417
16X16	0.016	0.4	0.047	1.188	55	1.28
16X16	0.018	0.457	0.0445	1.13	71.2	1.6
18X18	0.017	0.432	0.0386	0.98	69.4	1.6
20X20	0.02	0.24	0.03	0.76	76	0.56
20X20	0.016	0.33	0.034	0.86	72.2	1.1
20X20	0.014	0.35	0.036	0.92	52.5	1.225
20X20	0.016	0.4	0.034	0.87	46.9	1.6
20X20	0.0177	0.45	0.0322	0.82	41.7	2.025
22X22	0.012	0.3	0.034	0.854	54.76	0.99
24X24	0.014	0.35	0.028	0.708	44.77	1.47
30X30	0.014	0.35	0.0195	0.5	34.6	1.84
30X30	0.012	0.305	0.0213	0.54	63.9	1.4
30X30	0.0094	0.24	0.0243	0.62	72.1	0.84
35X35	0.0079	0.2	0.021	0.526	52.5	0.7
35X35	0.0098	0.25	0.0187	0.475	42.92	1.09
40X40	0.0079	0.2	0.017	0.435	46.9	0.8
40X40	0.01	0.254	0.015	0.38	59.9	1.3
40X40	0.014	0.35	0.011	0.285	20.14	2.45
50X50	0.0055	0.14	0.0145	0.368	72.4	0.48
50X50	0.0079	0.2	0.012	0.308	36.76	1
60X60	0.0047	0.12	0.012	0.303	71.6	0.42
60X60	0.0059	0.15	0.0107	0.273	64.5	0.65
60X60	0.007	0.18	0.0096	0.243	33	0.972
80X80	0.047	0.12	0.0078	0.1975	38.7	0.576
80X80	0.0055	0.14	0.0069	0.117	45.5	0.76
100X100	0.0039	0.1	0.006	0.154	36.76	0.5
100X100	0.0045	0.114	0.0055	0.14	55.1	0.59
100X100	0.004	0.102	0.006	0.152	59.8	0.49
120X120	0.0028	0.07	0.0057	0.147	67.7	0.29
120X120	0.003	0.08	0.0052	0.132	38.7	0.384
150X150	0.0024	0.06	0.0043	0.11	64.7	0.26
150X150	0.0028	0.07	0.0039	0.1	58.8	0.38
165X165	0.0019	0.05	0.0041	0.104	67.5	0.2
180X180	0.0019	0.05	0.0035	0.091	64.5	0.22
180X180	0.0024	0.06	0.0031	0.081	57.4	0.32
200X200	0.0019	0.05	0.003	0.077	60.6	0.24
200X200	0.0024	0.06	0.0026	0.067	52.7	0.35
250X250	0.0016	0.04	0.0024	0.0616	60.6	0.2
270X270	0.0016	0.04	0.0021	0.054	57.4	0.21
300X300	0.0016	0.04	0.0018	0.045	53.5	0.23
325X325	0.0014	0.035	0.0017	0.0432	55.3	0.2
400X400	0.0012	0.03	0.0013	0.0335	52.7	0.18
500X500	0.0009	0.025	0.001	0.0258	50.7	0.15
500X500	0.0012	0.03	0.0008	0.0208	16.76	0.225
635X635	0.0007	0.018	0.0008	0.022	55	0.1
